| Main Steel Frame | H section steel | Q235/Q355 grade steel 8mm/10mm |
| Welding | Automatic submerged arc welding | |
| Rust removal | Shot blasting Sa 2.5 | |
| Surface processing | Alkyd painting or galvanized | |
| Intensive bolt | Grade 10.9 | |
| Sub Steel Frame | Angle brace | L50x4, Steel Q235, processed and painted |
| Cross support | Φ20, Steel Q235, processed and painted | |
| Tie rod | Φ89*3, Steel Q235, processed and painted | |
| Bracing | Φ12, Steel Q235, processed and painted | |
| Standard bolt | Galvanized bolt | |
| Roof | Purlin | C#160,C#180,C#250, galvanized |
| Roof panel | Insulated sandwich panel or corrugated steel plate | |
| Skylight panel | 2.0mm FRP | |
| Accessories | Glass cement, self-tapping screws,etc | |
| Flashing/Trimming | Sheet steel profile | |
| Gutter | Galvanized sheet steel profile | |
| Water pipe | Φ110 PVC | |
| Walls | Purlin | C#160,C#180,C#250, galvanized |
| Wall | Insulated sandwich panel or corrugated steel plate | |
| Accessories | Glass cement, self-tapping screws,etc | |
| Flashing/Trimming | Sheet steel profile | |
| Ventilation | Axial fan | |
| Doors | Rolling door/sliding door | Automatic or manual |
| Windows | Sliding/fixed/shutter | Aluminum or PVC window frame |
| Floor plate | Steel deck | 1.0mm galvanized |
The advantageous for steel building
1. Large interior open spaces benefit for commercial structures, warehouses, workshops, storages, shopping center, stadium, etc
2. The system can use less steel to achieve the same structural scale, which is more economical.
3. They have immense strength, pretty much stronger and more durable than other construction materials, the main structure can last around 50 years.
4. All the framing components cut, welded, and drilled at the factory, it makes the installation work at a high speed assembled at a construction site.
5. The steel building is also a green building system, cause steel can be recycled repeatedly that is energy efficient and eco-friendly.
Steel buildings can work for any building application
A.High-rise buildings like a multi-story office building, residential apartment buildings,
commercial buildings center etc.
B.Warehouse building, similar to the industrial buildings, manufacturing plants, steel workshop.
C.Agricultural buildings, grain barn, storage buildings, suburban buildings.
